Control elements in the remote control
The remote control is installed in the vehicle interior.
Displays
No. in
fig. 4,
page 4
Description
1 Display Shows the status reports.
2 On/Off switch P Switches the remote control on and off if the
main switch is at “I” or “1”.
Stops the generator.
3 START button Starts the generator if the remote control is
switched on and the main switch is at “I” or
“1”.
4 Petrol gauge Lights up if the petrol goes into reserve.
5 Oil gauge Lights up if the oil level is too low in the
engine.
No. in
fig. 4,
page 4
Description
6 AC supply Actual voltage output
7 Constant output Current capacity of connected consumer
8 Operating hours Time the generator is in operation
9 DC voltage Battery voltage
10 Messages Status reports of the generator (see chapter
“Display messages” on page 20)
