NECK ADUSTMENT
Make any adjustments gradually. The neck should normally be slightly
concave. Please check the curvature after each 1/2 turn of the truss rod
nut.
Check the curvature of the neck
● After tuning accurately, hold the guitar in the playing position. Then
press the first string at the first fret and the last fret, and measure the
gap between the string and fret at the eighth fret. In the same way,
measure this gap for the lowest string, and make adjustments so that
the gaps are in the range of 0.1- 0.2mm.
● Turning the nut clockwise can make the neck bulge, which can correct
the problem that the neck is too concave, and the string action is too
high.
● Turning the nut counterclockwise can make the neck concave, which
can correct the problem of buzzing caused by excessive neck convex.
6
8th Fret
0.1-0.2mm
If the
convex is
excessive
If the
concave is
excessive
Concave
Convex
