Donner Ultimate Comp - Features; Connections & Controls; DC 9 V Jack; LEVEL Knob

Connections & Controls
types for satisfying different musicians:
NORMAL: Providing a neutral optical
compressor sound with warmth
TREBLE: Providing a brighter optical
compressor sound with more bite.
●Carefully Selected Components
The Ultimate Comp is designed and
built with carefully selected components
to ensure best sound quality and road
performance. The solid Aluminum-alloy
chassis ensures touring reliability, and
True Bypass design gives you a
transparent tone.
Features
●Compact dual-mode optical
compressor pedal
●100% analog circuit
●Wide range tone controls suitable for
both vintage and modern players
●True bypass provides transparent tone
●LED indicator shows the working state
●Enduring, light-weighted Aluminum-
alloy chassisnum alloy casing and all
metal footswitch
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 10mA
Dimensions: 42x93.5x52mm
Weight: 225g
a
c
db
www.donnerdeal.com
f
e
f
LEVEL Knob:
Controls the output volume.
Tone Selector:
Switches from two modes:
NORMAL:
Neutral compression tone.
TREBLE:
Brighter compression tone.
TONE Knob:
Controls the effect tone.
COMP Knob:
Controls the intensity of compression.
Input Jack:
1/4” mono audio jack, for connecting
guitar.
Output Jack:
1/4” mono audio jack, for connecting
to an amplifier.
Footswitch and LED:
Tap to switch the unit on/off. The LED
will lit up when the effect is on.
g
g
h
h
h
a
DC 9V Jack:
For power supply, use a 9-volt DC
regulated by AC adapter, 500mA
(plug polarity is positive on the barrel
and negative in the center).
