Report No. STS200421001001E
EN 62368-1
Clause Requirement + Test Result - Remark Verdict
Shenzhen NTEK Testing Technology Co., Ltd
Supplementary information:
(#) Frequencies above and below 30 kHz
Note 2: BI: basic insulation; SI: supplementary insulation; DI: double insulation; RI: reinforced insulation.
*: According to 5.4.1.8.1 i), the working voltage to determine minimun creepage distances was measured after
the ignition of the lamp.
5.4.2.3 TABLE: Minimum Clearances distances using required withstand voltage N/A
Overvoltage Category (OV):
--
Pollution Degree:
--
Clearance distanced between: Required
withstand voltage
Required cl
(mm)
Measured cl (mm)
Basic / supplementary insulation
--
--
-- --
Reinforced insulation
--
--
-- --
Supplementary information:
1. BI: basic insulation; SI: supplementary insulation; DI: double insulation; RI: reinforced insulation;
5.4.2.4 TABLE: Clearances based on electric strength test N/A
Test voltage applied between: Required cl
(mm)
Test voltage (Kv)
peak/ r.m.s. / d.c.
Breakdown
Yes / No
-- -- -- --
Supplementary information: Not used the alternative method to determine the clearances.
5.4.4.2,
5.4.4.5 c)
5.4.4.9
TABLE: Distance through insulation measurements N/A
Distance through insulation
di at/of:
Peak voltage
(V)
Frequency
(Hz)
Material Required DTI
(mm)
DTI
(mm)
-- -- -- -- -- --
Supplementary information:
5.4.9 TABLE: Electric strength tests N/A
Test voltage applied between: Voltage shape
(AC, DC)
Test voltage (V) Breakdown
Yes/No
Functional:
