Door Entry Direct DC260 - 5 Break Glass

5 Break Glass
If the controlled door is on a fire escape route, you should
fit fail safe locking devices and a breaking glass unit for
emergency exit
N/C Orange
COM Purple
N/O Blue
Black GND
Red +12V DC
Brown D_IN
Yellow OPEN
Grey ALARM
White D1
Green D0
N/O
COM
N/C
N/O
COM
N/C
Note:
Use second POLE if available
