2000e & 2000eM Keypad Installation & Programming
Assigning Virtual Outputs to Physical Outputs
(Standalone Mode Only)
The keypad is equipped with nineteen Virtual Outputs and twelve
Physical Outputs. Virtual Outputs are functions that you can assign to
operate any Physical Output. Physical Outputs include the main relay
and aux relay on the keypad, the eight relays on the 2000-8EX Output
Module, and the two audio alerts on the keypad.
● Using Command 10, you can assign any Virtual Output to any
Physical Output or disable a Physical Output.
● Each Physical Output can have multiple Virtual Outputs
assigned to it.
Assigning Outputs
(Standalone Mode Only)
Command/Action Keys to Enter/Details
Assign Outputs
10 # virtual output # physical
output # ✱ ✱
Virtual Outputs Physical Outputs
1 – Lock Output 1 – Main Relay
2 – Alarm Shunt 2 – Aux Relay
3 – Propped Door 3 – External Relay 1
4 – Forced Door 4 – External Relay 2
5 – OUT2 5 – External Relay 3
6 – OUT3 6 – External Relay 4
7 – OUT4 7 – External Relay 5
8 – OUT5 8 – External Relay 6
9 – OUT6 9 – External Relay 7
10 – OUT7 10 – External Relay 8
11 – OUT8 11 – Audio Alert 1
12 – OUT9 12 – Audio Alert 2
13 – OUT10
14 – Duress Output
15 – Panic Output (see page 5)
Note: The keypad is equipped
with only two relays. The Output
Expansion Module (2000-8EX)
is required to use additional
outputs.
16 – Keypad Active Output
17 – Doorbell Output*
18 – REX Input Active
19 – Door Loop Input Active
*Note: The Doorbell Output also works in both Front End Modes.
Disable Virtual Output
10 # virtual output # 0 # ✱ ✱
Disable Physical Output
10 # 0 # physical output # ✱ ✱
Programming the REX/Door
Loop Outputs (Lock, OUT2-10)
49 # outputs # input # ✱ ✱
Outputs: Lock =1, OUT2 = 2,
OUT3 = 3, OUT4 = 4, etc
Input: REX = 0; Door Loop = 1)
Note: The default output settings are:
● Lock Output = Main Relay
● Alarm Shunt = Aux Relay
● Forced Door = Audio Alert 1
● Propped Door = Audio Alert 2.
Programming Output Times
(Standalone Mode Only)
Command/Action Keys to Enter/Details
Change Lock Output Time
11 # time # 0 # ✱ ✱ (1-255 sec)
Set OUT2 Time Duration
12 # ttt # mmm # ✱ ✱
Set OUT3 Time Duration
13 # ttt # mmm # ✱ ✱
Set OUT4 Time Duration
14 # ttt # mmm # ✱ ✱
Set OUT5 Time Duration
15 # ttt # mmm # ✱ ✱
Set OUT6 Time Duration
16 # ttt # mmm # ✱ ✱
Set OUT7 Time Duration
17 # ttt # mmm # ✱ ✱
Set OUT8 Time Duration
18 # ttt # mmm # ✱ ✱
Set OUT9 Time Duration
19 # ttt # mmm # ✱ ✱
Set OUT10 Time Duration
110 # ttt # mmm # ✱ ✱
Set Propped Door Time
44 # time # 0 # ✱ ✱ (10-990 sec)
Set Forced Door Time
45 # time # 0 # ✱ ✱ (10-990 sec)
Note:
● OUT2-10: ttt = time units, mmm = multiplier.
Example: “12 # 2 # 5 # ✱ ✱” = 10 seconds
(2 time units multiplied by 5 seconds = 10 seconds).
● The maximum value of ttt and mmm is 255 (255 x 255).
● The default output times (Lock Output, OUT2-10) are 5 seconds.
● To toggle the output enter 0 for both ttt and mmm
Example: 12 # 0 # 0 # ✱ ✱.
Programming Keypad Options
(Default settings are in bold)
Command/Action Keys to Enter/Details
Change Keypad Options 30 # option # setting # **
Option Setting
0 – Audio Keypress Feedback 0 = Disabled 1 = Enabled
1 – Visual Keypress Feedback 0 = Disabled 1 = Enabled
2 – Auto Entry 0 = Disabled 1 = Enabled
3 – Error Lockout 0 = Disabled 1 = Enabled
4 – User Lockout 0 = Disabled 1 = Enabled
5 – Two-Part Users 0 = Disabled 1 = Enabled
6 – Keypad Backlighting 0 = Disabled 1 = Enabled
7 – Keypad Backlight Dimming 0 = Disabled 1 = Enabled
8 – REX Processing Select 0 = Only when
door closed
1 = Always
9 – Red LED Dimming 0 = Off when
backlighting dim
1 = Always On
10 – Door Loop Output Processing 0 = Not when
lock latched
1 = Always
16 – Secured Series In/Out 0 = Records IN 1 = Records Out
18 – 8-Bit Burst Output 0 = Disabled 1 = Enabled
19 – WFE Red LED Select 0 = Disabled 1 = Enabled
20 – WFE Red LED Active State 0 = Low 1 = High
21 – WFE Green LED Select 0 = Disabled 1 = Enabled
22 – WFE Green LED Active State 0 = Low 1 = High
Note: WFE means Wiegand Front End
To Next Page
