Reduce the risk of injury or death to a pedestrian by installing a
non-contact sensor directly under the arm.
The barrier gate operator CANNOT sense a pedestrian under the raised arm without installing an external safety device.
To help protect against an arm lowering on a pedestrian, install a photo sensor directly under the arm.
NOT A WALKWAY
NOT A WALKWAY
947GHT4
DoorKing Pedestrian Safety for Vertical Barrier Arm
IMPORTANT: A barrier gate operator installed WITHOUT any
external safety sensors CANNOT sense a person under the raised
arm and can strike them while the arm is lowering.
This scenario is VERY DANGEROUS and MUST NEVER OCCUR!!
See pages 10 through 17 for more information on how to wire the pedestrian photo sensor.
When the photo beam gets
interrupted by a pedestrian,
a lowering arm will reverse
and raise.
Photo Sensor
Moving Gate Can Cause
Serious Injury or Death
KEEP CLEAR! Gate may move at any time
without prior warning.
Do not let children operate the gate or play
in the gate area.
This entrance is for vehicles only.
Pedestrians must use separate entrance.
