DoorKing 1803 Installation & Owner's Manual

27
1800-060 Issued 7-19
Version A
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter a two-digit number of rings, then press (beep).
3. Press together to end this programming sequence (beeeeeep).
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) to set Switch Input 1, OR (beep) to set Switch Input 2.
3. Press (beep) to set to activate the relay, OR (beep) to set the switch input to dial-out a
preprogrammed phone number.
4. Press together to end this programming sequence (beeeeeep).
? ? ? ?
8
1
0
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) to set Relay 1, OR (beep) to set Relay 2.
3. Enter the four-digit tone open number code, then press (beep).
(Example: If you want a relay to have a momentary activation function ONLY, and you want that relay to momentary activate
when the number 9 is pressed, enter 9 # # #. If a function is not desired, enter # in place of a number. DO NOT duplicate
4-digit tone open numbers, Example: DO NOT set any of Relay 1’s 4-digit tone open numbers to the same number - 9879.)
4. Repeat steps 2 and 3 to set other relay tone open numbers.
5. Press together to end this programming sequence (beeeeeep).
0
0
0
? ? ? ?
1
2
1
1
2
5
0
These steps will program the tone open numbers for Relays 1 and 2. You will need to enter a four-digit number (see chart
below) to set the relay functions. If a function is not desired, enter # in place of a number.
Fill out log table in back of this manual for desired tone open numbers.
Factory setting is: Relay 1 = 9876, Relay 2 = 5432.
3.1.6 Tone Open Numbers
1st Digit
2nd Digit
3rd Digit
4th Digit
Relay 1- 9
Relay 1- 8
Relay 1- 7
Relay 1- 6
Relay 2- 5
Relay 2- 4
Relay 2- 3
Relay 2- 2
Momentary activation. Relay will activate for the programmed strike time (3.1.3).
Relay hold. Relay will activate and remain activated until commanded to release.
Relay release. Deactivates the relay hold command.
Relay hold 1-hour. Relay will activate for 1-hour and then will automatically deactivate itself.
4-Digit Tone Open Number Code Function
Note: Residents will only be able to activate the Momentary activation when using the entry system.
This programming sequence will set how the TWO switch inputs on the telephone entry system control board will operate.
Switch input 1 is labeled PSW (postal switch) and is found on terminal 4 of the main terminal strip. Switch input 2 is a two
terminal auxiliary input located on the upper left hand corner of the control board. These switch inputs can be programmed to
activate their respective relays (switch 1 - relay 1, switch 2 - relay 2). They can also be programmed so that switch 1 dials out
the phone number programmed in directory code 0, 00, 000, or 0000, and switch 2 dials out the phone number programmed in
directory code 1, 01, 001, or 0001. Each switch is programmed independently.
Factory setting = Switch input 1 = 0 (relay 1 activates), Switch input 2 = 0 (relay 2 activates).
3.1.7 Programming Switch Input 1 and Switch Input 2
?
?
?
?
?
?
?
?
3
3
DEF
DEF
2
2
ABC
ABC
This programming sequence sets the number of rings to allow before the telephone entry system answers a call placed to it.
This programming sequence does not affect the number of times that a resident’s telephone will ring when a call is placed from
the entry system to the resident.
Factory setting = 02 (two rings).
3.1.8 Number of Rings Before Telephone Entry System will Answer
? ? ? ?
3
2
