Presentation
Parking Brake
The parking brake is a wet disk brake built into the front axle. The
brake is applied by spring force and is released hydraulically.
Steering System
The machine uses a load sensing, hydrodynamic steering
system. It has a steering arc of 40°.
Cabin
The cabin has a heating and ventilation system with defrosting
for front and rear windows. Air-conditioning is standard. The
cabin has two emergency exits, the door and right side window.
FOPS and ROPS
The cabin is approved as a protective cabin according to FOPS
and ROPS standards. FOPS is an abbreviation of Falling Object
Protective Structure (roof protection) and ROPS is an
abbreviation of Roll Over Protective Structure (roll over
protection).
Never carry out any unauthorized alterations to the cabin, e.g.
lowering the roof height, drilling, welding on brackets for fire
extinguisher, radio aerial or other equipment, without first having
discussed the alteration with personnel at the DOOSAN
Infracore Engineering Department. This department will decide
whether the alteration may cause the approval to become void.
It is important that all parties concerned are aware of these
regulations.
Hydraulic System
The hydraulic system use a triple vane pump which contains
three pumping sections. The first pumping section supplies oil
for the front attachment. The second pumping section supplies
oil for the steering cylinders. Surplus oil which is not necessary
for the steering function is directed into control valve to join the
first pump is oil by the priority valve. Pilot pump oil is used for
brake and pilot line operation.
Equipment
The machine can be provided with different types of optional
equipment, depending on the requirements of different markets.
Examples of such equipment are emergency steering, pallet fork
and rear full fender.
