OP000754Operating Controls
2-16
6. Transmission Oil Temperature Gauge
This gauge displays temperature of oil in transmission
converter and transmission circuit.
7. Hour Meter
A LCD meter that records total time. When engine is
running, the hourglass icon blinks every four seconds. This
shows that the hour meter is working.
8. Left Turn and Hazard Warning Light
This light blinks when left turn signal is turned "ON." Both
lights blink when warning lights are turned "ON."
NOTE: If left and right turn indicators blink together, or if
they blink faster than normal, a light bulb is not
operating or flasher solenoid is damaged.
FG003950
Figure 29
CAUTION!
When the pointer indicates red zone, it means the
transmission is overheated. Stop the operation, let the
engine run at low rpm and wait for transmission to
cool down.
Figure 30
10
1
HA0O2012
FG004173
Figure 31
