Copyright Doosan 2006K1025196E Operation and Maintenance Manual
DOOSAN reserves the right to improve its products continuously, delivering the best possible product to the
marketplace. These improvements can be implemented at any time with no obligation to change materials
previously sold. It is recommended that consumers periodically contact their distributors for most recent
documentation on purchased equipment.
This documentation may include attachments and optional equipment not available in your machine's package.
Please call your distributor for additional items that you may require.
Illustrations used throughout this manual are used only as a representation of the actual piece of equipment, and
may vary from the actual item.
Operation and Maintenance Manual
K1025196E
Serial Number 5001 and Up
September 2006
DX35Z

Table of Contents

Questions and Answers

  • S
    Sharon HardySep 17, 2025
    Why is there a leaky oil seal in my Doosan DX35Z?
    • E
      ericbarajasSep 18, 2025
      A leaky oil seal in Doosan Excavators can be caused by various factors including foreign material in the spool or seal, excessive pressure, a bent lever or linkage, a damaged return spring, uneven valve temperature, high back pressure in the valve return line, a damaged spool, or a cracked/damaged seal. Solutions include cleaning or replacing the valve housing assembly, checking and adjusting pressure, removing and checking the linkage, replacing the return spring, warming up the entire system, cleaning the seal, increasing the size of the return line or replacing the valve housing assembly, or replacing the seal.
  • S
    Susan LeblancAug 25, 2025
    Why is there an unusual sound from my Doosan DX35Z Excavators hydraulic pump?
    • J
      josepharnoldAug 25, 2025
      An unusual sound from the hydraulic pump in Doosan Excavators can be attributed to several causes: cavitation from a bent suction side hose or clogged suction filter, cavitation from suction side fittings and air in the system due to low oil level, cavitation due to high viscosity oil, pump and engine misalignment, or air in the hydraulic oil. Suggested solutions include replacing the hose and filter, tightening fittings and adding oil, replacing the oil, readjusting the shaft, or bleeding the system.
  • P
    Paula WrightAug 25, 2025
    What causes oil leaks in Doosan Excavators?
    • J
      Jack JohnstonAug 26, 2025
      Oil leaks in Doosan Excavators can stem from seals leaking or a worn O-ring, or parts sticking due to foreign material. The suggested solution is to replace worn or damaged parts and disassemble, check for damage, and clean the affected components.
  • M
    Monica RogersAug 27, 2025
    Why is there a lack of cylinder power in my Doosan DX35Z Excavators?
    • D
      Danny MartinezAug 27, 2025
      A lack of cylinder power in Doosan Excavators can occur if the relief valve pressure is set too low, if there's an oil leak from inside the cylinder, if the cylinder piston or rod is damaged, or if there's an oil leak from inside the control valve. To resolve this, adjust the pressure, replace the cylinder seals, replace the piston or rod, or replace the valve housing assembly.
  • L
    Leroy AnthonySep 18, 2025
    Why is there no pressure rise in my Doosan DX35Z?
    • D
      Darryl TrevinoSep 18, 2025
      If the pressure does not rise in your Doosan Excavators, it could be due to an oil leak from inside the pump, air in the pump, or the main relief valve pressure being set too low. To fix this, replace the pump, add oil or check the suction side hose, or adjust the pressure.
  • B
    Benjamin HarrellSep 23, 2025
    What to do if there is an oil leak from outside pump in Doosan Excavators?
    • R
      Robert WatsonSep 23, 2025
      If there is an oil leak from the outside pump in Doosan Excavators, it is likely due to a bad hydraulic pump seal. Replace the seal or pump to resolve this issue.
  • C
    Christina LeonSep 9, 2025
    What causes a Doosan DX35Z Excavators hydraulic motor to not allow turning to one side?
    • C
      Cole WelchSep 9, 2025
      If a Doosan Excavators hydraulic motor will not allow turning to one side, it could be due to a bad control valve relief valve or a counterbalance valve spool sticking. To fix this, clean or replace the relief valve, or replace the counterbalance valve.
  • A
    Alexis UnderwoodSep 10, 2025
    What causes Doosan Excavators to fail to bear load?
    • M
      Mark JohnsonSep 10, 2025
      If Doosan Excavators fail to bear a load, it may be due to a leaky spool or a leaky port relief valve. To resolve this, replace the valve housing assembly relief valve or disassemble, clean, or replace the port.
  • K
    Kimberly AshleySep 3, 2025
    How to troubleshoot a Doosan Excavators swing motion that drags while stopping?
    • J
      johnsonvictorSep 3, 2025
      If the swing motion drags while stopping on your Doosan Excavators, it could be due to a low port relief or brake valve pressure setting, or foreign material in the port relief or brake valves. To fix this, adjust the pressure or clean the valves.
  • C
    Christopher JohnsonSep 1, 2025
    How to fix spool sticking in Doosan DX35Z?
    • G
      Gregory SimonSep 1, 2025
      Spool sticking in Doosan Excavators can occur if the hydraulic oil is excessively hot due to blockage, if the hydraulic oil is fouled, or if the valve housing is deformed due to overtightened fittings on the hydraulic oil line. To resolve this, remove the blockage, change the oil and clean the oil passages, or replace the valve housing.

Doosan DX35Z Specifications

General IconGeneral
BrandDoosan
ModelDX35Z
CategoryExcavators
LanguageEnglish
