G420F(FE) Service Manual Chapter 3. Engine Mechanical System 84
Removal
1. Remove the breather hose and P.C.V hose.
2. Remove the center cover.
3. Remove the ignition coil.
4. Remove the timing belt upper cover.
5. Remove the cylinder head cover.
6. Remove the tensioner.
7. Loosen the camshaft sprocket bolt and remove
the cam-shaft sprocket.
8. Loosen the bearing cap bolt and after removing
the bear-ing cap, remove the camshaft.
9. Remove the timing chain.
10. Remove the HLA.
To Next Page
