Doosan HP5100 - Table of Contents

124
HP5100 HP51MTE87
Contents
No.
Alarm
number
Alarm Name Page
1 2001
OP Emg. Stop PB or LS Off
126
2 2002
Main Spindle Servo Alarm
128
3 2003
Circuit Protector Tr
ip
130
4 2004
Hyd. Pump Motor Overload
132
5 2005
Hyd. Pressure Down Alarm
1
34
6 2009
ATC
Servo or Inverter Alarm
137
7 2010 Spindle Tool Unclamp Cmd. Fault
138
8 2015 Spindle Tool Unclamp Alarm
140
9 2020 Coolant & Lub. Pump Overload
142
10 2021 Air Pressure Down Alarm
175
11 2023
M06 Command Overtime Alarm
162
12 2036
Magazine Rotation or Matrix Illegal Position Alarm
167
13 2037 M06 Command Illegal Pos.
171
14 2041 APC Overtime Alarm
173
15 2042
M61 / M62 Command Illegal Position
176
16 2048
ATC
Door Open
180
17 2050
Lub. Level Low or
Pressure Down
184
18 2051
Oil cooling Unit Alarm
186
19 2052
Filter Change Alarm For TSC Unit
195
20 2060 Spindle Tool CL/UNCL Overtime Alarm 196
21 2063 ATC Arm Pin Alarm 198
22 2064 Waiting Tool Pot Spindle/Magazine Side Alarm 200
23 2065 Changer Arm Position Check Alarm 203
24 2073 Pallet or Table CL/UNCL Switch Alarm 207
25 2074 ATC Overtime Alarm 211
26 2075 ATC Magazine Rotation Over Time Alarm 215
27 2077 Waiting Pot & Spindle Tool No. Zero 218
28 2078 ATC OP Manual Mode 220
29 2080 ATC or APC Interlock Alarm 222
30 2081 ATC Magazine Guard Door Open 226
31 2084 APC Set-Up Station Door Open 228
