851-953 Rev. A 5 Dorner Mfg. Corp.
Variable Speed VFD Controllers
Specifications
Sanitary Controllers
Torque Specifications
Model
Number
Input Voltage
(VAC) & Phase
Input
Frequency
(Hz)
Output Voltage
(VAC) & Phase
Max. HP
(kW)
Max.
Output
in Amps
76MVA1122S
115 Volts,
Single Phase
60
230 Volts,
Three Phase
0.5 (0.37) 2.3
76MVA2122S
230 Volts,
Single Phase
60
230 Volts,
Three Phase
0.5 (0.37) 2.3
76MVA2322S
230 Volts,
Three Phase
60
230 Volts,
Three Phase
0.5 (0.37) 2.3
76MVA4342S
460 Volts,
Three Phase
60
460 Volts,
Three Phase
0.5 (0.37) 1.2
76MVA1121S
115 Volts,
Single Phase
60
230 Volts,
Three Phase
1.0 (0.75) 5.8
76MVA2121S
230 Volts,
Single Phase
60
230 Volts,
Three Phase
1.0 (0.75) 4.3
76MVA2321S
230 Volts,
Three Phase
60
230 Volts,
Three Phase
1.0 (0.75) 4.3
76MVA4341S
460 Volts,
Three Phase
60
460 Volts,
Three Phase
1.0 (0.75) 2.2
76MVA2127S
230 Volts,
Single Phase
60
230 Volts,
Three Phase
2.0 (1.50) 7
76MVA2327S
230 Volts,
Three Phase
60
230 Volts,
Three Phase
2.0 (1.50) 7
76MVA4347S
460 Volts,
Three Phase
60
230 Volts,
Three Phase
2.0 (1.50) 5.8
NOTE
All Dorner OPTIDRIVE™ VFD’s are supplied
with an inline line filter to meet EN 61800-3 or
other EMC standards. Consult the safety
information section of the vendor manual.
Flat Head Socket Head Button/Low Head Set Screw
Size Torque Size Torque Size Torque Size Torque
M4 x 0.7 2.5 mm 3.4 Nm
(30 in lbs)
3 mm 5.9 Nm
(52 in lbs)
2.5 mm 2.9 Nm
(26 in lbs)
2 mm 2.1 Nm
(19 in lbs)
M5 x 0.8 3 mm 6.9 Nm
(61 in lbs)
4 mm 12.0 Nm
(106 in lbs)
3 mm 5.9 Nm
(52 in lbs)
2.5 mm 4.7 Nm
(42 in lbs)
M6 x 1.0 4 mm 12.0 Nm
(106 in lbs)
5 mm 20.3 Nm
(180 in lbs)
4 mm 10.0 Nm
(89 in lbs)
3 mm 7.7 Nm
(68 in lbs)
M8 x 1.25 5 mm 28.0 Nm
(248 in lbs)
6 mm 48.8 Nm
(432 in lbs)
5 mm 24.0 Nm
(212 in lbs)
4 mm 17.8 Nm
(158 in lbs)
M10 x 1.5 6 mm 56.0 Nm
(496 in lbs)
8 mm 97.5 Nm
(863 in lbs)
6 mm 48.0 Nm
(425 in lbs)
5 mm 35.0 Nm
(310 in lbs)
