DOSATRON INTERNATIONAL / 22
CLEANING AND RE-ASSEMBLING THE SUCTION VALVE SEAL
- Turn off the water supply and allow the pressure to drop to zero.
- Loose the clamp on the suction hose with a screwdriver (Fig. 17-T)
and remove the suction hose.
- Unscrew and remove the black nut (Fig. 17-N).
- Pull downwards to remove the suction valve assembly.
- Remove the seal on top of the short valve (Fig. 17-C) and replace
it. Turn it around the nipple in order to be sure about its correct sea-
ting. Take care not to damage the listel.
- Proceed in the same way to change the seal of the long valve
(Fig. 17-L).
- Also change the o-ring (Fig. 17-J).
- Re-assemble in the reverse order to the above by hand.
N
C
L
J
T
Fig. 17
