SHIPPING CONTENTS : 1 DOSATRON / 1 mounting bracket for
DOSATRON + strap / 1 suction tube of concentrated additive / 1
strainer / 1 owner's manual.
PACKAGE SIZE :
40 x 17.5 x 17.5 cm [15 3/4" x 6 9/10" x 6 9/10"].
PACKAGE WEIGHT : 2 kg approx [~ 5 US lbs].
SPECIFICATIONS
DIA 2F DIA 4 RE
Practical operating flow range :
4.5 l/h MINI - 2.5 m
3
/h MAXI
[0.02 US GPM-11 US GPM]
Maximum operating temperature :
Minimum operating temperature :
40° C [104° F]
5° C [41° F]
Operating pressure :
BAR
PSI
0.15 - 5.5
[2.2 - 80]
0.15 - 4
[2.2 - 57]
Externally adjustable injection rate :
%
Ratio
2
[1:50]
1 - 4
[1:100 - 1:25]
Concentrated additive injection :
MINI l/h - MAXI l/h
US Fl. oz/min - MINI
US GPM - MAXI
0.090 - 50
0.051
0.22
0.045 - 100
0.026
0.36
Connections (NPT/BSP gaz male) : Ø 20 x 27 mm [3/4"]
Hydraulic motor capacity
(for every 2 clicks)
about 0.47 l
[0.124 US Gallons]
NOTE : The DOSATRON is not preset, see chapter
ADJUSTING THE INJECTION RATE.
UNIT SIZE
Diameter : cm ["] 15.2 [6] 15.2 [6]
Total heigh : cm ["] 33.6 [13 1/4] 36.5 [14.36]
Total Width : cm ["] 18 [7 1/8] 18 [7 1/8]
Weight : ± kg ["] 1.7 [3.7] 2 [4.4]
