LOWER END INJECTOR & WEAR PARTS KITS 0.4%:
Kit A – Wear Parts Kit (dosage piston and o-ring) 011851PV 17, 51
Kit C – Wear Parts Kit (Kit A, inner cylinder and o-ring) 011854PV 17, 51, 63,68
Kit D – Suction Tube Fitting (poppet, o-ring, nut/washer,
spring, fitting
011461V 10, 11, 12, 13, 71, 80
Kit E - Wear Parts (Kits C & D, inner cylinder (2nd inner
cylinder), shaft, pin, gasket)
011835PV 7, 10, 11, 12, 13, 16, 17, 51, 63,
64, 68, 71, 79, 80
Kit F – Lower End Cylinder Kit (inner & outer cylinder,
ratio adjuster, o-rings, retainer clip, pin, gasket)
011960PV 7, 16, 61, 63, 64, 65, 66, 67, 68,
79
Kit H – Motor Piston Assy (upper end kit) 011861 9
Kit M – Mounting Bracket Kit (mounting bracket, 4 hex
caps & nuts)
011432 56, 57, 58
Manual Reference Part # Description of Part
7 194404P Cylinder, inner
10 194418H Spring
11 194412 Fitting, suction tube, 3/8”
12 212120
*Must specify material
O-ring
13 011453A Poppet, check w/washer
15 194004 Seal retainer, o-ring
16 010016
*Must specify material
Gasket, inlet/outlet and cylinder
17 212005
*Must specify material
O-ring
25 011015 Suction tube, 3/8” x 5’
27 011026 Filter and foot valve, suction tube, 3/8” ID
51 011812
*Must specify material
Shaft, Assy with dosage piston
61 194406P Ratio adjustment sleeve
63 212516
*Must specify material
O-ring, inner cylinder (#68)
64 212017
*Must specify material
O-ring, inner cylinder, lower end
65 194310D Pin, upper interlock
66 212025
*Must specify material
O-ring, outer cylinder, lower end
67 011919P Cylinder, outer
68 011458 Cylinder, inner for #7
71 194414 Nut, suction tube fitting
79 194410SS Pin, narrow interlock
80 194415 Twistlock
15
