LOWER END INJECTOR & WEAR PARTS KITS 2.5%:
Description of Kit Part # Manual Reference
Kit A – Wear Parts Kit (dosage piston and o-ring) 011850V 17, 44
Kit B – Wear Parts Kit (Kit A, & shaft) 011945V 17, 44, 51
Kit C – Wear Parts Kit (Kit A, inner cylinder and o-ring) 011850CV 7, 17, 44, 64
Kit D – Hose Kit (o-ring, suction tube fitting, check valve, 2
adapters, clamp, hose, filter)
011849M 60
Kit F – Lower End Cylinder Kit (inner & outer cylinder, ratio
adjuster, o-rings, retainer clip, pin, gasket)
011961V 7, 16, 61, 64, 65, 66, 67, 79
Kit H – Motor Piston Assy (upper end kit) 011861 9
Kit M – Mounting Bracket Kit (mounting bracket, 4 hex caps &
nuts)
011432 56, 57, 58
Manual Reference Part # Description of Part
7 194404P Cylinder, inner
14 212005
*Must specify material
O-ring
15 194004 Seal retainer, o-ring
16 010016
*Must specify material
Gasket, inlet/outlet and cylinder
17 212005
*Must specify material
O-ring
44 010044
*Must specify material
Dosage Piston
51 194301F Shaft, with ears
60 011849M Hose braid kit
61 194406P Ratio adjustment sleeve
64 212017
*Must specify material
O-ring, inner cylinder, lower end
65 194310D Pin, upper interlock
66 212025
*Must specify material
O-ring, outer cylinder, lower end
67 194407P Cylinder, outer
79 194410SS Pin, narrow interlock
