LOWER END INJECTOR & WEAR PARTS KITS 5%:
Description of Kit Part # Manual Refer-
ence
Kit A – Wear Parts Kit (dosage piston and oring) 011852PV 17, 44
Kit B – Wear Parts Kit (Kit A, & shaft) 011950V 17, 44, 51
Kit C – Wear Parts Kit (Kit A, inner cylinder and o-ring) 011856PV 7, 17, 44, 64
Kit D – Hose Kit (oring, suction tube fitting, check valve, 2 adapters, clamp,
hose, filter)
011849M 60
Kit F – Lower End Cylinder Kit (inner & outer cylinder, ratio adjuster, o-rings, retainer
clip, pin, gasket)
011963PV 7, 16, 61, 64,
65, 66, 67, 79
Kit H – Motor Piston Assy (upper end kit) 011861 9
Kit M – Mounting Bracket Kit (mounting bracket, 4 hex caps & nuts) 011432 56, 57, 58
Manual Reference Part # Description of Part
7 194405P Cylinder, inner
14 212005VH o-ring
15 194004 Seal retainer, o-ring
16 010016
*Must specify material
Gasket, inlet/outlet and cylinder
17 212005
*Must specify material
O-ring
44 194309 Dosage Piston
51 194301F Shaft, with ears
61 194406P Ratio adjustment sleeve
64 212017
*Must specify material
O-ring, inner cylinder, lower end
65 194310D Pin, upper interlock
66 212025
*Must specify material
O-ring, outer cylinder, lower end
67 011918P Cylinder, outer
79 194410SS Pin, narrow interlock
60 011849M H
OSE BRAID KIT
