+12V POWER
as the ground cable, making sure you install in-line fuse holder, approximately 11 inches to 16 inches
GROUND ( GND )
Keep this cable as short as possible (not longer than 20 inches ).
Making sure that the connection with the chassis is rust free and clear of paint or grime.
REMOTE ( REM )
Connect the REM terminal of the amplifier to the power antenna terminal or the dedicated remote
turn on using 12 or 16 ga. electrical wire.
Caution
THE JP-84 is not supplied with internal fuses.
Make sure you install an in-line fuse holder
HEAD UNIT
GROUND
BATTERY
