DPM TT Series User Manual

DOWNLOADINGDATA
TTSeriesLR Manual
Page13

Important: OnlyuseagenuinecableandCD Rom fromDPMeasurement.
Ifanyotheraccessoriesortheincorrectdownloadingsoftwareareusedthenthe
guaranteeontheinstrumentandtheaccessoriesbecomesnullandvoid.
Allchargesapply.
DownloadData: Softwaremustbeinstalled.
EnsurethatthecableisconnectedtothePCviatheD‐typeconnector.
ConnecttheplugtotheRS232socket.
Doubleclickthemmuploadicon.Awindowwillappearonscreen,selectthe
comm.portandclicktheUploadoption.Anotherwindowwillappearonscre
en.
Givethefileaname;choosewhichfoldertosaveitinandthenpresssave.The
windowwillcloseandaprogressbarwillappearonscreen.Whenthedatais
downloaded,themessage‘Recordsreceivedsuccessfully’willappear,clickOK.
ClosethedownloadingsoftwareandopenthefileusingNotepad.

MAINTENANCE&CALIBRATION
TTSeriesLR Manual
Page13


Maintenance: TherearenouserserviceablepartsintheTTSeriesMicromanometers.
Withtheexceptionofdrycellbatteriestherearenoconsumableparts.
Iftheinstrumentisdamagedorrequiresservicing,itshouldbereturnedtothe
BuckinghamEnglandfactory.

Calibration:













AllTTSeries instrumentsarecalibratedagainstequipmenttraceabletoNational
Standards.Itisgoodpracticetohavetheinstrumentcalibratedandcheckedat
leastonceayear.
TheBuckinghamEnglandfactoryoffersacalibrationservice:





DPMeasurement
Unit11,TopAngel,Buc kinghamIndustrialPark
Buckingham,England.MK181TH
Tel/Fax:+44(0)1280817122
www.ttseries.com
email:dpm@ttseries.com




ManufacturedintheUnitedKingdom.

