DPM TT Series User Manual

TTSeriesLRManual
Page04
DISPLAY



AutoZero... Whenevertheautozerosequenceisinitiatedmanuallyoratpreset
‘AutoZero...’willbedisplayeduntilthecycleiscomplete.
Beinganautoranginginstrument,theresolutionanddecimalpointswill
changeaccordingtothepressurebeingapplied.

Slow4 Showswhichmodetheinstrumentisin.
PresstheFASTSLOWkeytochangethemode.

7.7
m/s
Showstheunitofmeasurement.
PressUNITStotogglebetweenunitsofmeasurement.

AvgVel
4.5

Showsthe averagevelocityofthereadingsstored.
Store
10
Showsthenumberofreadingsstored.
Upto2500readingscanbestored.


TTSeriesLRManual
Page04
PRESSURECONNECTIONS

Gauge/DuctStatic
Measurement:
ConnecttoSignalIn. LeaveReferenceopentoatmosphere.
Readingsmaybepositiveornegativedependingonwhetherthesystem
undertestisaboveorbelowatmospherepressure.

OrificePlates: ConnectupstreamtappingtoSignalInanddownstreamtappingtoReference.
Pressurereadingsshouldalwaysbepositive.

FlowGrids: Connect+VetappingtoSignalInand‐VetappingtoReference.
Pressurereadingsshouldalwaysbepositive.

InletCones: ConnecttappingtoSignalInusing‘T’piecestojointheannulartapping
together.LeaveReferenceopentoatmosphere,ensuringthattheopenport
isshieldedagainstsignificantairmovementfromtheingoingairstream.
Pressurereadingsshouldalwaysbenegative.

TotalHeadProbe: ConnecttoSignalIn.LeaveReferenceopen.
Readingsshouldalwaysbepositive

dpm‐iPitotTube: InputthePitotTubefactor0.838.
ConnectcleartubingtoSignalInandblacktubingtoReference.
UseUNITStotoggletom/sorft/mindependinguponmodel.
Readingsshouldalwaysbepositive.

EllipsoidalPitotTube: InputthePitotTubefactor1.000.
ConnectcleartubingtoSignalInandblacktubingtoReference.
UseUNITStotoggletom/sorft/mindependinguponmodel.
Readingsshouldalwaysbepositive.

 
AutoZero... Slow4
7.7
m/s
AvgVel Store
4.5 10
