5.PARK mode test
a)Press MODE again to light on the PARK cursor and LED.
b)Six samples were successively crossed at 7 – 10cm (2.7-3.9’’)above
the search coil.
c)Bass as the nails cross.5 ￠ nickel coins, pull ring, 1 ￠ zinc coins
across the medium sound.10 ￠ copper and 25 ￠ silver crossed.
d)As the metal sample crosses, the corresponding target cursor flashes,
and the digital cursor displays the corresponding number.(See graph 12,
with 25 ￠ zinc coin, for example)
graph 12
6. SAND mode test
a)Press the MODE button again, the SAND cursor and LED will light up
b)Swipe the six samples in sequence 7-10cm above the probe.
c)When the nails passed, the machine made no sound and the iron was
eliminated.
