WDS 6.4, 6 -TON ELECTRIC WOOD SPLITTER
DR 6 -TON ELECTRIC WOOD SPLITTER Controls and Features
NOTE: The model shown in Figure 1 may look slightly different from your machine.
Figure 1
Wedge
Ram
Operating Handle
Wheels
Oil Pump
Assembly
Electric Motor On-Off Switch
Electric Motor Assembly
Front Support Leg
A
ssembl
y
Powe
r
Cord
Log Guides
A
ir Bleed Scre
w
Dip Stick/
Hydraulic
Fluid Port
Controls Label
A
ir Bleed Screw Labe
l
Safety Label Operating Label
Electric Motor Shroud
Reset Button
Rear Lifting
Handle
Front Lifting Handle
Attachment Hole*
*The hole provided is for the Safety J-Hook supplied
with the Optional Stand. See page 28.
