DR 6-TON User Manual

2 DR
®
WDS 6.4, 6 -TON ELECTRIC WOOD SPLITTER
Specifications for the DR 6 -TON ELECTRIC WOOD SPLITTER
MAXIMUM RAM FORCE 12,000 lbf
MAXIMUM LOG LENGTH 20"
MAXIMUM LOG DIAMETER 16"
MAXIMUM RAM TRAVEL (TYPICAL) 17"
CLOSED GAP 4"
RAM CYLINDER DIAMETER 2.8"
RAM CYCLE TIME (TYPICAL)
21.5 seconds at low speed/high
pressure and 11 seconds at high
speed/low pressure
VALVE TYPE 2-Speed Valve
RAM RETURN MECHANISM Spring
RAM FACE 5" x 5"
HYDRAULIC FLUID RESERVOIR 6.5L
HYDRAULIC FLUID for 40ºF to 105ºF AW32
HYDRAULIC FLUID for -20ºF to 105ºF Dexron Auto Transmission Fluid
WEDGE HEIGHT 6"
MOTOR RPM 3450
MOTOR HORSEPOWER (Output)
1.8 HP - Continuous
2.7 HP Peak
MOTOR VOLTAGE 120 V/ 60hz
MINIMUM OPERATING VOLTAGE 105 V
POWER CORD 6' UL Certified
RECOMMENDED EXTENSION CORD 12 Gauge--Up to 33' Length
WHEEL SIZE 6.5"(dia.) x 2" width
WEIGHT OF UNIT 169lbs
UNIT SIZE L x W x H
41.5" x 15" x 20.5"
BOX DIMENSIONS L x W x H (no pallet) 43.5" x 13.5" x 23"
SHIPPING DIMENSIONS ON PALLET
L x W x H
43.5" x 14" x 28"
SHIPPING WEIGHT ON PALLET 202lbs
