DR K10 RAPIDFIRE User Manual

18 DR
®
K10 RAPIDFIRE™ LOG SPLITTER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Flywheel and Guard Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
72 353971 Leg Assembly
73 361031 Nut, Finish, M8, ZP
74 337431 Washer, Lock, M8
75 353931 Frame
76 364291 Bolt, HCS, M8 - 1.25 mm X 110 mm, CL 8.8,
ZP
77 337431 Washer, Lock, M8
78 361031 Nut, Finish, M8, ZP
79 354051 Cradle, Log
80 354061 Spacer, Cradle, Log
81 302601 Bolt, HCS, M8-1.25 X 100 mm, CL 8.8, ZP
82 361031 Nut, Finish, M8, ZP
82-1 337431 Washer, Lock, M8
83 337031 Bolt, HCS, M8-1.25 X 25 mm, CL 8.8, ZP
83-1 337431 Washer, Lock, M8
83-2 361031 Nut, Finish, M8, ZP
84 354081 Key, Flywheel, 8 mm X 7 mm X 20 mm
85 353991 Pinion
86 354041 Cover, Flywheel, Left
87 337031 Bolt, HCS, M8-1.25 X 25 mm, CL 8.8, ZP
87-1 337431 Washer, Lock, M8
87-2 361031 Nut, Finish, M8, ZP
88 353911 Flange, Bearing
89 353921 Flywheel
89-1 363181 Screw, Set, M8 X 1.0 X 8mm
90 361011 Snap Ring, External, 24 mm X 1.2 mm
91 360931 Bearing, Roller, 30mm X 55mm X 13mm
92 363251 Screw, M5-.8 mm X 10 mm
93 364321 Washer, Flat, M5
93-1 364331 Washer, Split-Lock, M5
94 364271 Belt, A1180
95 354011 Cover, Center
96 364371 Cover, Belt, Right, Small
97 354001 Cover, Flywheel, Right
98 354031 Bracket, Cover
