5. Secure the Wheel onto the Axle with a Cotter Pin. Use Pliers to bend the
ends of the Cotter Pin to secure the Wheel (Figure 11).
6. Repeat for the Wheel on the opposite side.
7. Tighten the Axle Bracket Hardware you installed in step 2.
8. Tip the Frame and Base over onto the Wheels.
Assembling and Installing the Power Unit
(Use Power Unit Hardware Package, see Figure 7)
Tools Needed:
1/2" Wrench
Two 3/4" Wrenches
Flat Head Screwdriver or 9/32" Wrench
1. Place the Outlet Chute on top of the Impeller Housing (make sure to orient
it as shown) and secure with four Bolts, Lock Washers, and Flat Washers
using a 1/2" Wrench (Figure 12).
2. Position the Power Unit at the front of the Rear Frame with the Tow Hitch
facing forward (Figure 13).
Note: Clevis Pins and Hitch Clips needed for the next steps are provided in the
Product Package.
3. Lift the Rear Frame and Power Unit to align the two sets of side holes and
insert a 1/2" X 3.5" Clevis Pin into each (Figure 14).
4. Secure each Clevis Pin with a Hitch Clip.
5. Place the two 1/2-13 X 2.75" Bolts from underneath up through the two
vertical Holes and secure with 1/2-13 Locknuts using two 3/4" Wrenches
(Figure 15).
1/2-13 Bolts
and Locknuts
Figure 15
Clevis Pins and
Hitch Clips
Figure 14
Figure 13
Rear
Frame
Side
Hole
Tow
Hitch
Side
Hole
Figure 11
Washer
Cotter Pin
We recommend having a helper to attach the Frames together. There is a
chance for injury if you attempt alone because the Power Unit is heavy.
