DR PILOT User Manual

8 DR
®
PILOT™ LEAF and LAWN VACUUM
Chapter 2: Setting Up the DR PILOT™ LEAF and LAWN VACUUM
It may be helpful to familiarize yourself with the controls and features of your DR PILOT™ LEAF and LAWN VACUUM as shown in
Figure 1 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR PILOT™ LEAF and LAWN VACUUM Controls and Features
Collector Sleeve
Hose Support
Dump
Leve
r
Collector
Outlet
Chute
Collector
Base
Power Unit
Wheels
Figure 1
Pneumatic
Tires
Tow Hitch
Choke
A
ir Filte
r
Gas Shut-Off
Starter Recoil Handle
On/Of
f
Switch
Gas Fill
Inlet Hose with Cuff
Muffler
Throttle
