DR PRO-62V - Filling Oil and Installing Battery

12 DR
®
PRO-62V CHAINSAW
Filling the Oil tank
1. Remove the Oil Tank Cap and add #32 Bar & Chain Oil to the top line of the
Oil Level Window (Figure 10). Replace and tighten the Oil Tank Cap.
Installing the Battery Pack
1. Slide the Battery Pack into the Battery cradle on the Chainsaw Housing,
aligning the ribs in the cradle with the slots in the Battery until it is latched
into place (Figure 11).
2. Check that the Battery is securely locked into place.
Removing the Battery
To remove the Battery, press and hold the Battery Self Lock Button on the left
side of the Chainsaw Housing and slide the Battery out of the Chainsaw.
Figure 10
Oil Tank
Cap
Oil Level
Window
Figure 11
Battery
Self Lock
Button
Chainsaw Housing
