Replacing the Carbon Canister
Tools needed:
• Wire Cutters
• Pliers
1. Turn the Fuel Shut-Off Valve to the CLOSED position.
2. Cut Cable Ties securing Carbon Canister to Gas Tank Plate using wire
cutters (Figure 63).
3. Remove Hose Clamp for better access to hoses.
4. Slide hose clamps away from hose connections using pliers. Twist as you
pull hoses from Canister.
5. Install hoses onto new Carbon Canister. Position hose clamps onto ends
with pliers.
Note: Install hoses onto new canister in the same location as they were on
old canister. The canister is labeled “Purge” (this hose is from the engine)
and “Tank” (this hose is from the top of the fuel tank).
6. Slide new Cable Ties through Canister Brackets. Position canister on
brackets. Make sure filter is installed pointing down.
7. Tighten cable clamps around canister and cut excess with wire cutters.
