Chapter 7: Parts Lists and Schematic Diagrams
Parts List – Frame and Tow Bar
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0004085436 SUPPORT-WHEELS W/LABELS
2 A0004085451 PUSH BAR - TB60
3 397101 PUSH BAR-REAR TB2 52IN
4 397181 GUARD-PUSH-BAR TB2 52IN
5 365731 BOLT - HEX - FLANGE - 1/2-13 X 4.5 -
GR8 ZP
6 333351 NUT-NYLON LOCK FLANGED 1/2-13
7 352811 BOLT-HEX FLANGE TL 3/8-16 x 3/4
8 354981 CASTER - FRONT - BRUSH
9 354811 WHEEL - 11 X 4-5IN - FLAT FREE -
SMOOTH TRD
10 343241 BOLT-HCS 3/4-10 x 7 GR5 ZP
11 333381 NUT-NYLON LOCK FLANGED 3/4-10
12 186551 PIN-COTTER 3/16x2 IN
13 A0000332299 ZERK-GREASE 1/4-28 STRAIGHT
14 10000025089 WHEEL - 13 X 5-6IN - LUG TREAD -
TUBELESS
15 396461 OFFSET BRACKET TB2 GP
16 A0000253563 PIN CLEVIS 1/2 X 4.5IN L ZP
17 234991 WASHER - 0.53 ID X 1.06 OD X 0.095 -
ZP
18 160031 PIN-HITCH CLIP 1/2-9/16
Ref# Part# Description
19 354961 TOW - BAR
20 345111 BOLT - HEX - FLANGE - 1/2-13 X 3 - GR5
ZP
21 255491 PIN CLEVIS - 1/2 X 2 1/2IN TRT
22 354971 EXTENSION - TOW BAR
23 363081 EXTENSION - TOW BAR BALL HITCH
24 246481 COUPLER-2 IN BALL-3 IN MOUNT
25 333491 BOLT -HEX - FLANGE - 1/2-13 X 5
26 10000031528 CLAMP-LOOP 3/4IN ID X 1-13/16 LONG
27 111701 SCREW - 10-32x1/2 TYPE F
28 362891 BUSHING - SWAY BRACE
29 354941 BRACE - SWAY
30 365721 BOLT - HEX - FLANGE - 1/2-13 X 3.5 -
GR5
31 334431 LINK - CHAIN THREADED CONNECTOR
- WR3
32 253121 CHAINS - SAFETY 36IN INDIVIDUAL
33 395001 BRACKET-CHAIN GUARD
34 363171 WELDED CHAIN 1/4 IN GRADE 30
PROOF TB2
35 395011 ROD-RETENTION-CHAIN GUARD
36 365821 LABEL - HEIGHT ADJUST - LEFT - TB2
37 365811 LABEL - HEIGHT ADJUST RIGHT - TB2
