DR PRO MAX 60T - Page 37

CONTACT US AT www.DRPower.com 37
Parts List – Deck Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0004085437 DECK - TB60 IN W/LABELS
2 397131 CHANNEL-SUPPORT-LEFT TB2 52IN
3 397121 CHANNEL-SUPPORT-RIGHT TB2
52IN
4 352811 BOLT-HEX FLANGE TL 3/8-16 x 3/4
5 A0004085467 RAIL-SUPPORT-LEFT TB60
6 A0004085438 RAIL-SUPPORT-RIGHT TB60
W/LABELS
7 A0000762114 COVER-BELT-TB2-EXTENDED
8 A0004085504 IDLER ARM - TB60
9 322061 BUSHING - 0.386 X 0.623 X 1.53IN
FT1
10 112391 WASHER-FLAT 3/8 USS
11 A0000367023 WASHER - SPLIT - 3/8 - GR8 - ZP
12 333481 BOLT-HEX FLANGE 3/8-16 x 2.5
13 A0004085496 BOLT-HCS FT 3/8-16X3 1/2 GR8 ZP
14 151271 PULLEY FLAT IDLER 4 IN
15 333331 NUT-NYLON LOCK FLANGED 3/8-16
16 373411 SPRING - 1.00 OD - 0.135 WIRE - 5.5
L
17 A0004085499 SPACER-.394 ID X 1.38 OD X .91
18 365631 BOLT - HEX - FLANGE - 1/2-13 X 1.25
-GR8 ZP
19 A0004085503 SPACER - IDLER - TB60
20 350511 SPACER-IDLER
21 245571 BOLT - HCS - 3/8-16 X 4 GR5
22 362591 SPINDLE ASSEMBLY - BRUSH
23 350391 WASHER - 1.06ID X 2OD X 0.13ZP
24 A0004085474 PULLEY V-BELT 8-1/2 IN OD 1 IN ID -
TB60
25 322371 KEY - ANSI 806 WOODRUFF - 1/4 X
3/4
26 333381 NUT-NYLON LOCK FLANGED 3/4-10
27 362611 CAP - SPINDLE – BRUSH
Ref# Part# Description
28 A0004085475 GUARD - ANTI WRAP - TB60
29 A0004085473 BLADE 31.5 IN AIR TIP
30 363071 WASHER-BLADE CARRIER-TB2
31 A0004085472 BOLT - HEX - FLANGE - 3/4-10 X
2.25-GR8
32 A0004085505 GUIDE - BELT - TB60
33 A0004085478 LINK-PIVOT LIFT SYSTEM - TB60
34 A0004085469 ACTUATOR - LINEAR 8000 N 80 MM
STROKE
35 397331 PIN-ACTUATOR-60MM
36 397351 PIN-ACTUATOR-40MM
37 235001 PIN - COTTER 7/64 X 1 ZP
38 397341 PIN-ACTUATOR-50MM
39 A0004085447 FRONT CHAIN GUARD – TB60
40 A0004085476 COVER - PULLEY - TB60
41 112411 WASHER – FLAT 5/16 USS
42 A0001922549 PANEL-RELAY MOUNT TB2 52
43 150491 SCREW-8-32 x 1/2
44 A0001079296 NUT-LOCK SERRATED FLANGE 8-32
45 10000031528 CLAMP-LOOP 3/4IN ID X 1-13/16
LONG
46 111701 SCREW - 10-32x1/2 TYPE F
47 A0004085442 BRUSH BAR - TB60 IN - RH
48 A0004085443 BRUSH BAR - TB60 IN - LH
49 385981 BOLT-HEX FLANGE 5/16-18 x2-1/2
GR8
50 333321 NUT-NYLON LOCK FLANGED 5/16-
18
51 385991 BOLT-HEX FLANGE 5/16-18 x 1-3/4
GR5
