DR PRO MAX 60T - Page 39

CONTACT US AT www.DRPower.com 39
Parts List – Drive Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 352811 BOLT-HEX FLANGE TL 3/8-16 x 3/4
2 A0004085470 MOUNT MOTOR-TB60
3 A0004085466 PLATE-FUEL TANK TB60
4 A0004085477 PLUG DIA 1.25
5 112411 WASHER-FLAT 5/16 USS
6 289901 SCREW-UNSLTD TRILOBE 3/8-16 x 1
7 A0004085439 ENGINEKAWASAKI 24HP 726CC
W/LABELS
8 0A4456 WASHER LOCK SPECIAL 3/8
9 A0000253565 SPACER-CLUTCH
10 370501 CLUTCH-OGURA-GT1.5A-GR02
11 191301 WASHER-FLAT .469 ID x 1.62 OD .25
L GR5
12 A000366994 BOLT-7/16-20 x 2-1/4 GR8 ZP
13 333331 NUT-NYLON LOCK FLANGED 3/8 16
14 A0004085493 BELT-TB60
15 A0004149743 FUEL TANK ASSY-2.5 GAL MULTI
LAYER
16 385811 STRAP – TANK – 3/8-16 STUDS
17 265771 BRACKET, CARBON CANISTER
18 150491 SCREW-8-8-32 x 1/2
19 385301 CARB CAN 300CC 1/4 TANK 3/16
PRG
20 127971 CABLE TIE-17 IN 50 GA
21 A0000522190 HOSE-FUEL EPA/CARB CERTIFIED
22 A0000313387 CLAMP-FUEL LINE
23 362861 VALVE – FUEL SHUTOFF
24 A0000522190 HOSE-FUEL EPA/CARB CERTIFIED
25 A0000522190 HOSE-FUEL EPA/CARB CERTIFIED
26 10000032635 CLAMP-LOOP 3/8 IN ID 13/32 IN MNT
HOLE
27 292511 M8 FLAT WASHER - ZP
28 10000040536 HOSE-VAPOR 3/16 IN ID
29 265811 CLAMP-VAPOR HOSE
30 10000031528 CLAMP-LOOP 3/4 IN ID x 1-13/16
LONG
31 A0004085486 MANIFOLD EXHAUST KAWASAKI
24HP VTWIN
32 A0004085487 MUFFLER EXHAUST KAWASAKI
24HP VTWIN
33 220981 BOLT HEX HEAD M8 X16
34 279601 CLAMP-EXHAUST-1.25 IN
35 A0004085490 SPARK ARRESTER - KAWASAKI
24HP VTWIN
Ref# Part# Description
36 A0004085492 GUARD - MANIFOLD - REAR - TB60
37 A0004085482 BRACKET-BATTERY TB60
38 A0004085483 STRAP-BATTERY U1 BOX TB60
39 A0004085484 BATTERY BOX TB60
40 0D4575 BATTERY BCI GROUP U1
41 187571 BOLT-HCS 5/16-18x3-3/4
42 333321 NUT-NYLON LOCK FLANGED 5/16-
18
43 179121 BOLT-TRI 1/4-20 x 1/2
44 A0004085488 CONTROL PANEL - TB60
45 179291 ADAPTER-PLUG-MAINT METER
46 217201 MAINT METER-W/66IN WIRE
47 10000029087 CABLE-THROTTLE-14IN
48 222231 SWITCH-SNAP-IN ES TB1
49 157201 KEY-IGNITION SWITCH
50 A0004085489 CHOKE - CABLE - TB60
51 111701 SCREW - 10-32x1/2 TYPE F)
52 A0001944323 WIRE HARNESS-TETHER RELAY
TB60
53 A0000149422 SWITCH-ROCKER DPDT (ON)-OFF-
(ON)
54 191231 SWITCH PUSH/PULL TPDT
55 A0000303132 COVER-CONTROL BOX-52 IN
56 10000024617 SCREW-NO. 4 X .375 TORX TYPE AB
57 A0000303131 BOX-CONTROL-52 IN
58 A0004085449 WIRE HARNESS-RELAY TB60
ACTUATORS
59 A0004085450 WIRE HARNESS - MACHINE TB60
60 A0004085454 WIRE - BATTERY GROUND TB60
61 112501 WASHER-STAR LOCK 5/16
62 118731 NUT-LOCK NYLON 10-24
63 112141 CABLE TIE 7-1/2 IN L
64 114781 SCREW-PANHEAD 10-24 x 5/8 IN
65 123211 BOLT-HCS 5/16-18 x 3/4 GR5 ZP
66 110761 NUT-LOCK NYLON 5/16-18
67 0L0878 COVER BATTERY POST ELL-TRON
47
68 A0004085435 LABEL - THROTTLE CONTROL PRO
MAX60T
69 10000036023 DECAL PROP 65 SHORT FORM
70 A0004085481 LABEL-PRO MAX60T
71 A0000188793 LABEL-DR LOGO-4IN-RED
72 127811 LABEL-WARNING ADD OIL
73 G079552 DATA DECAL OVER LAMI
74 389131 LABEL-RAISE/LOWER
