CONTACT US AT www.DRpower.com 13
Never stop the engine by moving the throttle control lever to the choke
position. This could cause an engine backfire resulting in engine damage.
Before Starting the Engine
1. Check the oil level every time you use the machine. See your Engine Owner’s
Manual.
2. Check the gasoline level.
3. Open the Fuel Shut-Off Valve on the left hand side of the Mower (Figure 13).
4. Make sure the Blade Control Safety Cover is pushed down to the disengaged
position (Figure 14).
Note: The Blade Switch Safety Cover must be pushed down or the Engine will not
start.
Starting
1. Ensure the Blade Switch Safety Cover is down (Figure 14).
2. When starting a cold Engine, push the Throttle Control Lever up to the
Choke
position (Figure 15). When starting an already warm Engine,
push the Throttle Control Lever to the Run
position.
3. Turn the Key Switch to the Start
position until the Engine starts, then
release. The Key will snap back to the center On
position and the
Engine will continue to run.
4. As the Engine warms up, slowly adjust the Throttle to the Run
position.
Wait until the Engine runs smoothly before each Throttle adjustment. For
maximum performance, operate the Engine with the Throttle in the Run
position.
Stopping the Engine
1. Disengage the Blades by pushing the Blade Control Safety Cover down
(Figure 14).
2. Move the Throttle Control Lever all the way down to the Idle
position
and turn the Key to Stop
(Figure 15).
3. Remove the Key for safety.
Note: Close the Fuel Shut-Off Valve when transporting or storing the TOW-
BEHIND DR FIELD and BRUSH MOWER (Figure 13).
Throttle
Leve
Key
Switch
Figure 15
Figure 14
Blade Switch
Safety Cover
Figure 13
Fuel Shut-Off
Valve Open
Inspect the area where you will be working. The site must be free of
potentially hazardous obstacles such as glass, large stones, sticks, wire, rope,
and string-like materials. Make sure there are no people or animals in the
area around the TOW-BEHIND DR FIELD and BRUSH MOWER.
