26
TOW BEHIND DR
®
FIELD and BRUSH MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Frame and Tow Bar
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 37138 Support, Wheels, Brush, Right, with Labels
2 36581 Label, Height Adjust, Right
3 37125 Label, Crank Direction
4 37139 Support, Wheels, Brush, Left, with Labels
5 36582 Label, Height Adjust, Left
6 37120 Guard, Push Bar
7 36273 Push Bar
8 35498 Caster, Front, Brush
9 35482 Wheel, 13 X 5-6, Lug Tread
10 35481 Wheel, 11 X 4-5, Flat Free, Smooth Tread
11 35495 Bracket, Offset
12 35496 Tow Bar
13 35497 Extension, Tow Bar
14 36317 Welded Chain, 1/4", Grade 30 Proof Coil, 8
Links
15 36316 Rod, Retention, Chain Guard
Ref# Part# Description
16 36315 Bracket, Chain Guard
17 34324 Bolt, HCS, 3/4-10 X 7, ZP
18 36573 Bolt, Hex, Flange, 1/2-13 X 4.5", GR5, ZP
19 34511 Bolt, Hex, Flange, 1/2-13 X 3", GR5, ZP
20 35281 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X 3/4",
GR5 ZP
21 11170 Screw, 10-32 X 1/2", Type F, Hex, ZP
22 23499 Washer, SAE Flat, 1/2", ZP
23 33338 Nut, Nylon Lock, Flanged, 3/4-10
24 33335 Nut, Nylon Lock, Flanged, 1/2-13
25 18655 Pin, Cotter, 3/16" x 2"
26 18737 Pin, Clevis, 1/2" OD X 4.5" LG
27 25549 Pin, Clevis, 1/2" X 2 1/2"
28 16003 Pin, Hair, 1/2" To 9/16", .12" Wire
29 36311 Cable Clamp, .75" Bundle, #10 Screw
