DR PRO-XL Operating Instructions

8 TOW BEHIND DR
®
FIELD and BRUSH MOWER
Specifications
16.5 HP Pro Model 20 HP Pro-XL Model
Engine See your Engine Manual for oil
capacity and other Engine
s
p
ecifications.
See your Engine Manual for oil
capacity and other Engine
s
p
ecifications.
Starting System Electric Start Electric Start
Fuel Tank 2.5 Gal. (9.46 L), Gasoline,
Unleaded
2.5 Gal. (9.46 L), Gasoline,
Unleaded
Battery 9Ah 9Ah
Wheels Front: 11 X 4-5, Flat Free
Rear: 13 x 5-6, Lu
gg
ed
(
with tube
)
Front: 11 X 4-5, Flat Free
Rear: 13 x 5-6, Lu
gg
ed
(
with tube
)
Tether Length 14'-5" 14'-5"
Distance From
Centerline To Outer
Cutting Edge
68" - full offset
49.5" - mid offset
68" - full offset
49.5" - mid offset
Number of Offset
Positions
5 5
Adjustable Cutting
Height
From 4"min. to 7-1/2" max. From 4"min. to 7-1/2" max.
Cutting Width 44" 44"
Cutting Capacity
4' high grass, 8'-high weeds &
brush, 3" thick saplings
6' high grass, 8'-high weeds &
brush, 3" thick saplings
Blade Tip Speed 18,500 - 19,000 ft/min 18,500 - 19,000 ft/min
Blades Break Away/Swing, Air Tipped Break Away/Swing, Air Tipped
Deck 12 GA Welded Steel 12 GA Welded Steel
Discharge Rear Rear
Spindle
1-3/8" Dia. Shaft with 2 Sealed 30
mm Bearings
1-3/8" Dia. Shaft with 2 Sealed 30
mm Bearings
Belt
B49 B49
Electric Clutch 75 ft-lb 95 ft-lb
Fuses 20 AMP Type AGC Fuse (Engine
Alternator Circuit)
7 AMP Type AGC Fuse (Clutch
Circuit)
20 AMP Type AGC Fuse (Engine
Alternator Circuit)
7 AMP Type AGC Fuse (Clutch
Circuit)
Max Speed Mow/Tow
5mph 5mph
Tongue Weight 10 lbs. 10 lbs.
Machine Dimensions 146" L x 46.5 " W x 29.5" T 146" L x 46.5 " W x 32.5" T
Machine Weight 358 lbs. 401 lbs.
