28 TOW BEHIND DR
®
FIELD and BRUSH MOWER
Parts List – Deck and Deck Lift
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 35494 Brace, Sway
2 36289 Bushing, Sway Brace
3 36312 Acme Thread, Height Adjust
4 36574 Shim, Nylon, .76" ID X .1.31" OD X .06"
Thk
5 36576 4-Lobe Knob, 5/16-18 X 1/2" Stud, ZP
6 35499 Block, Height Adjust
7 36254 Crank, Hand
8 37121 Crank, Hand, Break-Away
9 37141 Deck, Brush, 44", w/Labels
10 13649 Label, Danger, Blade
11 37122 Label, Warnings
12 37134 Plate, Gas Tank, Brush, w/Labels
13 36580 Label, Branding
14 36259 Spindle, Assembly, Brush
15 32237 Key, ANSI #806 Woodruff, 1/4" X 3/4"
16 36546 Carrier, Blade
17 37110 Blade, Swinging, Air Tip/ w/Hardware
18 36307 Washer, Blade
19 36263 Idler Arm
20 36258 Bushing, .380" X .664" X .9"
21 36256 Pulley, 11" OD, 1" Bore, 1/4" Key, B
22 15127 Pulley, Flat Idler, 4"
23 36555 Spring, 1" OD, 8" L, .105" Wire
24 36288 Belt, B49
25 36564 Bolt, Hex, Flange, 3/4-10 X 1.75", GR5,
ZP
Ref# Part# Description
26 36563 Bolt, Hex, Flange, 1/2-13 X 1.25", GR5,
ZP
27 36572 Bolt, Hex, Flange, 1/2-13 X 3.5", GR5, ZP
28 34512 Bolt, Hex, Flange, 3/8-16 X .75", GR5, ZP
29 15712 Bolt, HCS, 3/8-16 X 2-1/4", GR5, ZP
30 11465 Bolt, HCS FT, 3/8-16 X 3", GR5, ZP
31 11148 Bolt, HCS, 1/4-20 X 1.75", GR5, ZP
32 11170 Screw, 10-32 X 1/2", Type F, Hex, ZP
33 35093 Washer, Flat, 1", ZP
34 11239 Washer, Flat, 3/8", USS
35 22253 Washer, Lock, 3/8"
36 33338 Nut, Nylon Lock, Flanged, 3/4-10
37 33335 Nut, Nylon Lock, Flanged, 1/2-13
38 36575 Nut, Acme, 1/2-10, GR2, ZP
39 33333 Nut, Nylon Lock, Flanged, 3/8-16
40 18755 Nut, Nylon Lock, 5/16-18, LP
41 11073 Nut, Nylon Lock, 1/4-20, ZP
42 36577 Detent Pin, Grip Ring, 1/4" X 1-1/4", ZP
43 36311 Cable Clamp, .75" Bundle, #10 Screw
44 37133 Rail, Support, w/Labels
45 35491 Mount, Motor, Brush
46 35492 Channel, Support, Left
47 35493 Channel, Support, Right
48 36255 Cover, Belt, Brush
49 37119 Mount, Molex
