30 TOW BEHIND DR
®
FIELD and BRUSH MOWER
Parts List – Drive, Gas and Control
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 37134 Plate, Gas Tank, Brush, with Labels
2 33386 Clutch, Electric, 75 Ft-Lbs, w/Key (16.5hp
Only)
35016 Clutch, Electric, 95 Ft-Lbs, w/Key (20hp
Only)
3 22142 Spacer, 1.00" ID X 1.75" OD X 1.25"
4 37146 Engine, B&S, 16.5HP, Pro Series, ES,
w/Labels
34448 Engine, B&S, 20HP V-Twin, w/Labels
and Exhaust
5 34130 Gasket, Exhaust, Briggs, 20hp Vtwin
(20hp Only)
6 35056 Bolt, Muffler, B&S, 20hp (20hp Only)
7 17912 Screw, 1/4-20 X .500", Tri-Lobe
8 13758 Label, Check Oil, 2.75" x .63"
9 13683 Label, Caution, Hot Surface
10 34444 Guard, Exhaust, B&S V-Twin (20hp Only)
11 36361 U-bolt, 1-1/8" ID, 1/4-20 x 1"
12 13447 Battery, 12V, 9ah
13 24230 Strap, Battery, 9ah
14 36304 Switch, Toggle, DPDT
15 37135 Control Panel, w/Labels
16 36585 Label, Throttle Control
17 28336 Fuel Tank Assy, 2.5 Gal, Certified
18 36549 Cable, Throttle, 30" L
19 35280 Muffler, B&S, 20HP, Horizontal (20hp
Only)
20 26575 Carbon Canister, 300cc, 3/16" Ports
21 36569 Hose, Vapor, 3/16" ID, 32" Long,
w/Clamps (20hp Only)
22 26581 Clamp, Vapor Line
23 36568 Hose, Vapor, 3/16" ID, 24" Long,
w/Clamps
24 22223 Switch, Snap-On, E/S
25 36571 Hose Fuel Ca Cert, 12" Long, w/Clamps
26 10066 Clamp Fuel Line
27 37113 Hose, Fuel, Ca Cert, 2" Long, w/Clamps
(20hp Only)
28 15720 Key, Ignition Switch
29 36286 Valve, Fuel Shutoff
30 12797 Cable Tie, 17", # 50
31 22237 Strap, Fuel Tank, 2.5 Gal
32 22214 Bolt, 7/16-20 X 2-1/4", GR8, ZP
Ref# Part# Description
33 35281 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X
3/4", GR5 ZP
34 34512 Bolt, Hex, Flange, 3/8-16 X .75", GR5, ZP
35 34325 Bolt, Hex, Flange, 1/4-20 X 1"
36 11170 Screw, 10-32 X 1/2", Type F, Hex, ZP
37 37112 Screw, Plastic Thread Forming, Pan
Head, # 2 Philips, #8-18 X 3/4", Stl, ZP
38 15049 Screw, 8-32 x 1/2"
39 19130 Washer, Flat, .469" X 1.62" X .25"
40 22252 Washer, Lock, 7/16", Split ZP
41 31283 Nut, Lock, 1/4-20, Serrated Flange
42 11073 Nut, Nylon Lock, 1/4-20, ZP
43 36552 Wire Harness, Machine
44 36550 Wire Harness, Tether
45 36551 Wire Harness, Hand Control
46 36303 Hand Control, Back
47 37137 Hand Control, Front, w/Labels
48 36584 Label, Blade Engage
49 36305 Safety Cover, Toggle Switch
Not Shown
34333 Deflector, Briggs (16.5hp Only)
34331 Muffler Guard, B&S (16.5hp Only)
34334 Static Cover, Briggs (16.5hp Only)
34332 Screw, Muffler guard (16.5hp Only)
34335 Screw, B&S, static cover (16.5hp Only)
15045 Bolt, HCS, 5/16-18x1 3/4, Gr5,zp,
ground (16.5hp Only)
11069 Nut, Finish, 5/16-18, zp, ground (16.5hp
Only)
11250 Washer, Star Lock, 5/16, ground (16.5hp
Only)
34275 Wire, Battery, Ground
37140 Label, QR Code
35507 Label, EPA/CARB 2015
26570 Hose, Vapor, 3/16" ID, 39" Long, w/
Clamps (16.5hp Only)
37114 Hose Fuel CA Cert, 20" Long, w/ Clamps
(16.5hp Only)
31283 Nut, Lock, 1/4-20, Serrated Flange
(located on starter motor)
17912 Bolt, Tri, 1/4-20x1/2, (ground, 20hp
Only)
