34 DR
®
POWERWAGON
Parts List - Drive Assembly
Note: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.
Ref# Part# Description
1 37913 Tube, Frame, Right
2 37914 Tube, Frame, Left
3 37909 Bracket, Angle, Skid Plate
4 38567 Plug, 1-1/2" OD, 12 GA Tube
5 35145 Bracket, Shift, Transmission
6 37389 Transaxle, 3 Spd, W/ Brake
7 35302 Wheel Assembly, Snow Hog, 4.8-8,
Keyed Hub
8 11114 Pulley, V, 7" OD 4l/A Belt
9 37923 Arm, Idler
10 37929 Bushing, Idler
11 11307 Pulley, Flat Idler, 2-1/4"
12 14409 Pulley, V-Belt, 2.625" OD, Idler
13 35261 Spring, Extension
14 38545 Belt, AP50
15 37915 Bushing, Belt Guide
16 37900 Pulley, 2.75" OD, 7/8" Shaft, A Belt
17 38578 Engine, B&S, 8.75 Pro, E/S, With Labels
38579 Engine B&S 7.25 EXI ES, W/Labels
38580 Engine B&S 6.75 EXI M/S, W/Labels
18 38547 Cable, Brake, 64" L
19 33333 Nut, Nylon Lock, Flanged, 3/8-16
20 33332 Nut, Nylon Lock, Flanged, 5/16-18
21 34326 Bolt, Hex, Flange, Grade 8, 3/8-16 X 3"
22 39086 Bolt, Hex, Flange, 3/8-16 X 2-1/4", GR8,
ZP
Ref# Part# Description
23 34407 Bolt, Hex, Flange, 3/8-16 X 1.5", GR5, ZP
24 35281 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X
3/4", GR5 ZP
25 11155 Bolt, HHCS 3/8-24 X .75", GR.2, ZP
26 38592 Bolt, Carr, 3/8-16 X .75", GR5, ZP
27 11173 Bolt, HCS, Serrated Flange 5/16-18 X
.50"
28 15045 Bolt, HCS, 5/16-18 X 1-3/4", GR5, ZP
29 11150 Bolt, SHCS, 1/4-18 X 3/4", Black Oxide
30 38591 Bolt, Carr, 1/4-20 X 2", GR5, ZP
31 38945 Washer, Flat,.75" X 1.125" X .012"
32 11238 Washer, Flat, 1/4"
33 11250 Washer Lock 1/4" External Tooth
34 11069 Nut, Hex, 5/16-18, GR2, ZP
35 33331 Nut, Nylon Lock, Flanged, 1/4-20
36 11124 Snap Ring, External, 5/8"
37 11126 Ring, Retaining, 3/4" E-Clip
38 10119 Key, Square, 3/16" X 2"
39 37911 Plate, Skid
40 37912 Mount, Engine
41 37930 Bracket, Brake
Safety Labels
13758 Label, Check Oil
