36 DR
®
POWERWAGON
Parts List – Premier Bed and Frame Assembly
Note: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.
Ref# Part# Description
1 38560 Bumper, Bed
2 16496 Grip, 1.00
3 39094 Premier Poly Bed, With Labels
4 37918 Tube, Support, Poly Bed
5 37927 Brace, Poly Bed
6 11108 Plug, 1" X 1" OD, 16GA tube
7 37925 Brace, Cartbed
8 38572 Handle, Dump, With Labels
9 38540 Spring, Torsion, 360 Deg, .063" Wire,
.798" OD
10 33805 Spacer, .327" ID X .51" OD X 2.69"
11 33335 Nut, Nylon Lock, Flanged, 1/2-13
12 33353 Bolt, Hex, Flange, 1/2-13 X 4", GR5
13 33333 Nut, Nylon Lock, Flanged, 3/8-16
14 33332 Nut, Nylon Lock, Flanged, 5/16-18
15 38598 Bolt, Hex, Flange, 5/16-18 X 2-1/2", GR8,
ZP
16 39085 Bolt, Hex, Flange, 5/16-18 X 3", GR8, ZP
Ref# Part# Description
17 10940 Bushing .395" ID X .500" OD
18 10877 Arm, Dump
19 39086 Bolt, Hex, Flange, 3/8-16 X 2-1/4", GR8,
ZP
20 38593 Bolt, Hex, Flange, 5/16-18 X 4", GR8, ZP
21 38599 Bolt, Hex, Flange, 5/16-18 X 1-3/4", GR5,
ZP
22 38597 Bolt, HCS, 5/16-18 X 5-1/2", GR5, ZP
23 35033 Bolt, Carr, 5/16-18 X 1.75", GR5, ZP
24 38594 Bolt, FHCS, 1/4-20 X .75", GR5, ZP
25 10668 Nut, Lock, Serrated Flange, 5/16-18
26 33331 Nut, Nylon Lock, Flanged, 1/4-20
27 37910 Bracket, Hinge, Transaxle
28 37928 Bracket, Bed Rest, Left
29 38562 Bracket, Bed Rest, Right
30 38563 Label, Branding, Bed
31 15342 Label, Dump Lever
To Next Page
