38 DR

POWERWAGON

Parts List – Pro and Pro-XL Bed Assembly

Note: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.

Ref# Part# Description

1 38560 Bumper, Bed

2 11108 Plug, 1" X 1" OD, 16GA tube

3 37924 Tube, Support, Cartbed

4 37925 Brace, Cartbed

5 38574 Cart Bed, With Labels

6 37933 Sidewall, Left, Cartbed

7 37934 Sidewall, Right, Cartbed

8 38573 Tailgate, With Labels

9 33335 Nut, Nylon Lock, Flanged, 1/2-13

10 37936 Bracket, Actuator, Dump Arm

11 37937 Linear Actuator, 12 V, 200 mm Stroke

12 33333 Nut, Nylon Lock, Flanged, 3/8-16

13 38596 Bolt, Hex, Flange, 3/8-16 X 1-3/4", GR5,

14 39084 Bolt, Hex, Flange, 1/2-13 X 1-1/2", GR5,

15 33332 Nut, Nylon Lock, Flanged, 5/16-18

16 38598 Bolt, Hex, Flange, 5/16-18 X 2-1/2", GR8,

17 39085 Bolt, Hex, Flange, 5/16-18 X 3", GR8, ZP

Ref# Part# Description

18 10940 Bushing .395" ID X .500" OD

19 10877 Arm, Dump

20 39086 Bolt, Hex, Flange, 3/8-16 X 2-1/4", GR8,

21 38593 Bolt, Hex, Flange, 5/16-18 X 4", GR8, ZP

22 38599 Bolt, Hex, Flange, 5/16-18 X 1-3/4", GR5,

23 35034 Bolt, Carr, 5/16-18 X 3", GR5, ZP

24 38594 Bolt, FHCS, 1/4-20 X .75", GR5, ZP

25 39083 Screw, Plastic Thread Forming, Pan

Head, # 2 Philips, #8-18 X 1/2", Stl, ZP

26 10668 Nut, Lock, Serrated Flange, 5/16-18

27 33331 Nut, Nylon Lock, Flanged, 1/4-20

28 37910 Bracket, Hinge, Transaxle

29 37928 Bracket, Bed Rest, Left

30 38562 Bracket, Bed Rest, Right

31 38587 Plate, Sidewall

32 38588 Rib, Sidewall

33 34139 Label, DR Logo, 4", 4 Color

34 38563 Label, Branding, Bed
