Dräger Alcotest 7000 User Manual

| Use
14 Dräger Alcotest
®
7000
4.6.1.1 Reading the result
The following settings depend on the configuration.
The preconfigured alcohol threshold values determine when the
yellow or red indicator lights up.
Three types of results are possible.
● No alcohol detected (see the fold-out page, Figure 2: D). The
green indicator also lights up. The device is ready for use again
after 2 seconds.
Or
● Low level of alcohol detected (see the fold-out page, Figure 2: E).
The yellow indicator also lights up. Press the button to proceed
with the next measurement.
Or
● Alcohol detected (see the fold-out page, Figure 2: F). The red
indicator also lights up. Press the button to proceed with the
next measurement.
Once the sensor's recovery time has elapsed (see "Technical data",
page 27), the display indicates that the device is ready for
measurement.
● Repeat step four of the process for taking an automatic breath
sample.
With passive breath samples
Two types of results are possible.
● No alcohol detected (see the fold-out page, Figure 2: G). The
green indicator also lights up. Press the button to continue with
the next measurement.
Or

Dräger Alcotest 7000 Specifications

General

Brand	Dräger
Model	Alcotest 7000
Category	Test Equipment
Language	English
