Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 529
Troubleshooting
!
(Masimo
rainbow
SET only)
SpO2 cable failure Cable failure
Parameter values
are replaced by ***
The Masimo rainbow
SET intermediate
cable is faulty.
Replace the
intermediate cable.
!
(Nellcor
OxiMax
MCable
only)
SpO2 check
sensor
2)
Check sensor
Parameter values
are replaced by ***
The SpO2 sensor is
disconnected.
– Make sure the
SpO2 sensor is
attached
properly to the
patient.
– Check all cable
connections.
None
(Masimo
rainbow
SET only)
%0 sensor
calibrating
1)
Sensor
calibrating
Parameter values
are replaced by ***
The sensor is being
checked for functional
integrity.
Wait until message
disappears.
This message
appears right
before the
message SpO2
searching.
None
(Any
SpO2
MCable)
SpO2 desaturation Parameter value SpO2 value below
Desat. limit.
– Check the
patient and
treat if
necessary.
– Change the
alarm limits.
Priority Message Parameter field Problem Solution
