Dräger Infinity Series Quick Reference Guide

Infinity Delta/Delta XL/Kappa - Quick Reference Guide
Intended for quick reference only.
Refer to Instruction For Use Manual.
INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 25
© 2010 Draeger Medical, Inc.
CO Problems
Calibrating
Cal. Failed –
Not Static
Cal. Failed –
Out of Range
Zero before Cal.
H/W Failure
Possible Cause
Mercury calibration in
progress.
Mercury calibration
failed b/c input pres-
sure was not static.
Mercury calibration
failed b/c the meas-
ured value was too
high or too low.
During calibration,
more than 5 minutes
have elapsed since
last successful zero.
IBP Channel hardware
failure.
Action
Complete calibration
before you begin
monitoring the patient.
Make sure transducer
is closed to patient.
Check for leaks. Keep
all tubing motionless.
Rezero the transducer.
Loosen and retighten
the transducer dome,
then rezero the
transducer. Replace
the transducer.
Make sure the trans-
ducer is zeroed, then
retry. If the retry fails,
replace the transducer.
If calibration requires a
factor outside this
range, replace the
transducer.
Zero the transducer.
Check hardware and
replace. Call Biomed
or Dräger Medical
Technical Support.
