Dräger Infinity Series Quick Reference Guide

Infinity Delta/Delta XL/Kappa - Quick Reference Guide
Intended for quick reference only.
Refer to Instruction For Use Manual.
INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 26
© 2010 Draeger Medical, Inc.
CO Problems
Hemo Pod
Disconnected
RESP Problems
Respiration value
appears incorrect.
RESP Out of Range
RESP Apnea (neonatal
or Peds mode only)
Possible Cause
The hemo pod is not
connected to monitor.
Possible Cause
Incorrect lead place-
ment, artifact.
The respiration rate is
higher than 150
breaths per minute.
The monitor may be
counting artifact as
valid breaths. The
monitor may be
counting interference
caused by faulty
equipment.
No respiration has
been detected.
Action
Check cables and
connection. Replace
cable if necessary.
Action
Check lead placement.
Change monitor lead
(I/II). Turn on respira-
tions Marker to denote
breath.
Check the patient and
treat if necessary.
Check the placement
of electrodes. Change
their position if neces-
sary. Move the elec-
trodes away from the
source of interference.
Check and or change
electrode placement if
necessary. Carry out a
RESP Relearn or reset
breath-detection sensi-
tivity in Manual mode.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
