Dräger Interlock 5000/7000 33
Technical data
5 Technical data
Measuring principle Electrochemical DrägerSensor
Measuring range up to 2.50 mg/l
Ambient conditions
for operation and storage –45 °C to 85 °C
20 % to 98 % r. h.
600 to 1100 hPa
No influence of changes in altitude on
the measurement result
Sensitivity drift Typically 1 % of measured value /
month
Display Display
Calibration interval Typically 12 months
Dimensions (H x W x D)
Handset approx. 140 mm x 60 mm x 36 mm
Control unit approx. 150 mm x 90 mm x 32 mm
Weight
Interlock 5000 handset approx. 170 g
Interlock 7000 handset approx. 180 g
Control unit approx. 195 g
Voltage supply 12 V to 24 V
Power consumption
maximum <2.5 A
stand-by <1 mA
Switch relay for the lead
for the starter relay
<16 A, continuous
<40 A, peak
Output relay
switchable de-energized 48 V
switchable energized 24 V
Ignition lead 5 V to 48 V
Waiting time to be ready for
measurement
Interlock 5000 Interlock 7000
20 °C 7 s2 s
0 °C 15 s<5 s
–25 °C <60 s <60 s
–45 °C <115 s110 s
