Instructions for use | Dräger Interlock
®
7500 25
Before selecting from the menu, the ignition of the vehicle must be switched
on.
To call up the menu:
● Press the Down/Menu button.
To navigate within the menu:
1. Select the menu item by pressing the Down/Menu button.
2. Confirm selection with OK button.
3. Select any sub-menu items by pressing the Down/Menu button and confirm
with OK button.
5.1 Breath test
This function provides the option of requesting a new breath alcohol test.
5.2 Service info
This function shows the date, the reason for the next service and the phone
number of the service centre.
5.3 Device info
5.3.1 Occupational times
This function displays the set timeframes in which a breath alcohol test can be
performed using the instrument. Outside of this timeframes, it is not possible to
carry out a breath alcohol test using the instrument.
5.3.2 Client info
This function shows information for client identification.
5.3.3 Handset info
This function displays the part number, the serial number and the software
version of the handset.
5.3.4 Control box info
This function displays the part number, the serial number and the software
version of the control unit.
5.3.5 Camera info
This function displays the part number, the serial number and the software
version of the optional camera.
5.3.6 Cellular/GPS info
This function displays the part number, the serial number and the software
version of the optional GPRS or LTE module.
49260
Occupational times
Client info
Handset info
Control box info
Camera info
Cellular/GPS info
Standby times
Date & Time
Service No.
Serial number
Date & Time
Enter code:
Display
Language
Communication
Service No.
Serial number
Date & Time
Enter code:
Back to menu
Breath test
Service info
Device info
Unlock device
Access code
Configuration
