drago GT - Deck Plate Tension; Gathering Chain Tension

INITIAL SETTINGS
Corn Head Clinic Guide - GT
14
DECK PLATE TENSION
Deck plate tension can be checked by seeing if the two adjusting bolts are
approximately centered between the two lines on the cover plate.
If adjustment is required see Section 6.6 in the Operators Manual.
GATHERING CHAIN TENSION
Check the gathering chain tension by pulling on the side of the gathering
chain until the tensioning fork hits the internal stop. Mark the tensioning
fork shaft and release the chain. The tensioning fork should have
1
/
4
" to
5
/
16
“of travel.
If adjustment is required see Section 6.7 in the Operators Manual.
