Draper DA200 - Getting to Know Your Compressor

DA200
(1) HANDLE.
(2) COWLING- covers, protects hot/moving parts.
(3) PRESSURE REGULATOR- adjusts output air pressure.
(4) AIR OUTLET CONNECTOR.
(5) FEET.
(6) ON/OFF SWITCH
(1) AIR RECEIVER- stores air.
(2) MOTOR COWLING- covers, protects hot/moving parts.
(3) PRESSURE GAUGE- indicates receiver air pressure.
(4) PRESSURE REGULATOR- adjusts output air pressure.
(5) SAFETY VALVE.
(6) AIR OUTLET VALVE.
(7) INSPECTION PLUG.
(8) FEET.
(9) O N/OFF SWITCH.
(1)
(2)
(3)
(4)
(5)
(6)
(8)
(9)
(5)
(1)
(6) (2)
(3)
(4)
DA6/200
& DA6/201
GETTING TO KNOW YOUR AIR COMPRESSOR
DA25/180
(1) AIR RECEIVER- stores air.
(2) MOTOR COWLING- covers, protects hot/moving parts.
(3) PRESSURE GAUGE- indicates receiver air pressure.
(4) PRESSURE REGULATOR- adjusts output air pressure.
(5) AIR OUTLET VALVE.
(6) INSPECTION PLUG.
(7) FOOT.
(8) ON/OFF SWITCH.
(9) WHEEL.
(10) DRAIN COCK.
(7)
(6)
(4)
(9)
(3)
(2)
(1)
(5)
(10)
(8)
(7)
- 5 -
