Draper FlexShade - Installing Side Channels: Wall or Face Mount

Data Cable
with RJ45
Connector
Data Hub
Bus Power
Supply
M12
Connectors
RS485
110VAC
Motor
RS485
110VAC
Motor
Controls & System Overview
Sonesse 485 120VAC Motors
BUS OUT
to next
DATA HUB
BUS IN
STOP
Wall Switch
110V
Outlet
110-120V Line110-120V Line
LAN
Dashed Wiring
by Electrician
Motorized FlexShade
®
with 485 Sonesse (ILT)
120VAC Operator
Fascia
Endcap
Cover (R)
Brackets
Only (L)
Brackets
Only (R)
Endcap (R)
for Fascia
Endcap (L)
for Fascia
Endcap
Cover (L)
M12
Cable
Retainer
Clip
page 7 of 8
Motorized FlexShade
®
